FUJI 2AGKNY010600 8.4x1.8 Rectangular Nozzle for SMT Placement Machine

FUJI 2AGKNY010600 8.4x1.8 Rectangular Nozzle for SMT Placement Machine

The FUJI 2AGKNY010600 Y0J Rectangular Nozzle is designed for compatible NXT H04S placement head applications requiring an extended rectangular pickup surface. With an 8.4 x 1.8 mm pickup specification, this nozzle provides a longer contact profile for suitable elongated electronic components during automated SMT assembly.

The nozzle works together with the placement head vacuum system to pick components from feeders, maintain stable holding force during high-speed movement, and release parts accurately at programmed PCB positions. Compared with shorter rectangular nozzle sizes, the 8.4 mm pickup length can provide a larger contact area where the component package offers sufficient flat surface.

The 2AGKNY010600 is suitable for production replacement, preventive maintenance and spare-parts inventory. Correct selection should always consider the component pickup surface, placement head configuration and current nozzle reference before installation.

Cause

Why Can Larger Rectangular Components Require a Dedicated Nozzle?

Electronic components vary significantly in length, width, surface structure and center of gravity.

When an elongated component is handled by a nozzle with an insufficient contact area, the component may become less stable during rapid machine movement.

Typical symptoms can include:

• Component movement after pickup
• Rotation during transfer
• Unstable vacuum readings
• Repeated pickup errors
• Component dropping
• Placement position variation

A properly selected rectangular nozzle helps increase usable contact with the component while maintaining vacuum sealing.

Nozzle Wear in High-Speed SMT Production

Placement nozzles operate continuously during production.

Over long operating periods, several conditions can affect performance:

When cleaning no longer restores reliable operation, nozzle replacement should be considered.

Solution

The 2AGKNY010600 8.4 x 1.8 mm rectangular nozzle provides a suitable replacement option where this pickup geometry is required.

Its extended rectangular tip is designed to provide controlled contact across a longer component surface.

For best production results:

1. Confirm the existing nozzle part number.
2. Verify the H04S head configuration.
3. Compare the new and existing nozzle profiles.
4. Inspect the component pickup surface.
5. Check the vacuum passage before installation.
6. Install the nozzle correctly.
7. Perform low-speed pickup testing.
8. Check component stability during movement.
9. Run sample PCB production.
10. Resume normal production after verification.

Specifications

Related Rectangular Nozzle Comparison

The 2AGKNY010600 provides the longest pickup profile among these four listed models.

It should not be selected simply because it is larger. The component must provide enough flat surface for the complete nozzle contact profile.

Application

PCB Assembly

The nozzle is suitable for automated PCB production using compatible NXT H04S head configurations.

It can support handling of suitable components where a longer rectangular pickup area is beneficial.

Consumer Electronics

Applicable production may include:

• Digital electronics
• Smart appliances
• Consumer control boards
• Electronic modules
• Communication devices

Automotive Electronics

Automotive PCB production often requires high repeatability and stable component handling.

Proper nozzle selection helps maintain consistent pickup during continuous high-volume operation.

Industrial Electronics

Suitable applications may include production of:

• Industrial control boards
• Automation modules
• Embedded systems
• Power electronics
• Machine controllers

EMS Manufacturing

EMS manufacturers frequently run multiple PCB models.

Keeping several nozzle sizes available helps production teams respond to different component packages and customer programs.

How It Works

1. Installation

The nozzle is mounted onto the compatible H04S placement head and connected to the machine vacuum circuit.

2. Pickup Positioning

The machine moves the head toward the programmed feeder location.

3. Component Contact

The rectangular tip approaches the selected top surface of the component.

4. Vacuum Activation

Vacuum passes through the nozzle and generates holding force.

5. Component Lifting

The component is lifted from the feeder while remaining attached to the nozzle.

6. Transfer

The head moves the component toward the PCB.

The longer pickup surface can help support stable handling where the component geometry is compatible.

7. Recognition

The machine performs the required component recognition and positioning correction.

8. Placement

The component is moved to the programmed PCB coordinates and lowered into position.

9. Release

Vacuum is released and the nozzle continues to the next placement cycle.

How To Choose

Confirm the Part Number

For this nozzle:

2AGKNY010600

Matching the existing part number is the preferred starting point for replacement.

Confirm the Nozzle Code

Y0J

The nozzle code provides an additional model identification reference.

Confirm the Head

NXT H04S

Different placement heads may use different nozzle configurations.

Check the Pickup Surface

The component should provide sufficient flat contact for the 8.4 x 1.8 mm rectangular profile.

Do not allow the nozzle to overlap:

• Component leads
• Raised edges
• Cavities
• Terminals
• Irregular surfaces

Evaluate Component Stability

For longer components, consider both pickup area and center of gravity.

The best pickup point should provide balanced handling throughout acceleration, recognition and placement.

Selection Checklist

Maintenance Recommendations

Regular nozzle maintenance helps prevent unnecessary SMT line interruptions.

Inspect the nozzle for:

• Vacuum blockage
• Dust accumulation
• Tip deformation
• Surface wear
• Physical damage
• Abnormal contamination

Use suitable nozzle cleaning procedures and avoid aggressive tools that may change the precision tip geometry.

Replacement nozzles should be stored separately in protective packaging.

FAQ

Q1: What is the FUJI 2AGKNY010600 nozzle specification?

The 2AGKNY010600 Y0J is a rectangular placement nozzle with an 8.4 x 1.8 mm pickup profile for compatible NXT H04S placement head applications.

Q2: Why choose an 8.4 mm rectangular nozzle?

Its longer contact profile can suit compatible elongated components that provide sufficient flat pickup surface and require stable vacuum holding during transfer.

Q3: How can I confirm compatibility?

Check the existing part number, H04S head model, nozzle dimensions and component pickup surface. Clear photos of the current nozzle can also help with model verification.

Q4: When should I replace the nozzle?

Replacement should be considered when the nozzle has visible wear, deformation, persistent blockage, unstable vacuum performance or repeated pickup errors after cleaning.

Q5: Can I order several nozzle models together?

Yes. Send the required part numbers, quantities and machine information so related nozzle models can be quoted together.

Contact Us

Looking for the FUJI 2AGKNY010600 Y0J 8.4 x 1.8 mm rectangular nozzle?

Please send us:

• Part number
• Machine series
• Placement head model
• Required quantity
• Existing nozzle photos
• Additional SMT spare-parts requirements

Contact us for pricing, availability and product confirmation.
