The FUJI R36-037G-260 AA08520 3.7G nozzle is a precision SMT pickup nozzle designed for FUJI NXT pick-and-place machines using H01 and H02 placement heads. Installed directly on the placement head, the nozzle provides the contact interface between the machine vacuum system and electronic components during pickup, transfer, recognition, and placement.

The complete identification combines R36-037G-260, AA08520, and 3.7G, making it easier for SMT engineers and purchasing departments to distinguish this model from other H01/H02 nozzle sizes and configurations.

This nozzle is suitable for routine replacement, preventive maintenance, production-line spare stock, equipment servicing, and SMT factories operating FUJI NXT equipment. Correct nozzle selection helps support consistent pickup behavior, reduce unnecessary component handling errors, and maintain reliable production performance.

Although the nozzle is a small part of the placement system, it operates continuously throughout the SMT production process. Each production cycle involves component pickup, vacuum holding, high-speed movement, positioning, placement, and release.

After extended operation, nozzle performance may be affected by contamination, mechanical wear, improper handling, or incorrect nozzle selection.

Typical nozzle-related problems include:

Nozzle problems should always be evaluated together with the feeder, vacuum system, component packaging, placement head condition, machine calibration, and production program.

Replacing a worn or unsuitable nozzle with the correctly identified model helps restore normal component handling performance.

For FUJI NXT machines equipped with compatible H01/H02 heads, the R36-037G-260 AA08520 3.7G nozzle provides a clearly identifiable replacement option.

For accurate purchasing, we recommend confirming all four references:

Using the complete model rather than ordering only by nozzle size can reduce purchasing errors because different FUJI nozzle families may have similar numerical descriptions.

FUJI H01/H02 heads use different nozzle sizes for different component and production requirements. Buyers should select the nozzle according to the approved machine setup and existing nozzle configuration.

For example:

R36-037G-260 = 3.7G

The letter G is part of the nozzle identification. Therefore, buyers should not automatically treat R36-037G-260 and other R36-037-series nozzles as identical.

When replacing an existing nozzle, checking the complete model is the safest purchasing method.

The FUJI AA08520 nozzle is mainly used in SMT production lines operating compatible FUJI NXT machines.

Suitable for PCB assembly lines producing electronic control boards for household appliances, smart devices, digital products, and consumer electronics.

Can be used in FUJI NXT production environments manufacturing automotive electronic assemblies, subject to the factory's approved nozzle configuration.

Suitable for production of industrial controllers, automation equipment, power electronics, sensors, control modules, and other PCB assemblies.

Applicable to SMT lines manufacturing telecommunication and network-related electronic assemblies.

Electronics manufacturing service providers often process different PCB designs and maintain multiple nozzle types for flexible production changeovers.

The nozzle can be stocked as a replacement part for preventive maintenance and emergency machine repair.

The nozzle operates as part of the FUJI NXT component placement cycle.

The placement head moves toward the programmed component pickup location.

Vacuum is applied through the nozzle to hold the electronic component securely during pickup.

The component is lifted from the feeder or other component supply position.

The placement head transfers the component toward the PCB while the nozzle maintains vacuum holding.

The machine's recognition system checks the component according to the programmed production process.

Required positional correction is applied before placement.

The placement head moves the component to the programmed PCB location.

The component is released onto the PCB, and the nozzle continues to the next production cycle.

Because these steps are repeated continuously, correct nozzle condition is important for stable production.

A correctly selected and well-maintained nozzle supports consistent component pickup and holding.

Keeping commonly used nozzles in stock allows maintenance teams to replace damaged parts quickly.

The combination of R36-037G-260, AA08520, and 3.7G makes purchasing and warehouse identification easier.

Factories can prepare replacement nozzles in advance instead of waiting until an installed nozzle fails.

The nozzle can be categorized and stored according to machine, head, size, model, and part number.

Verify that your equipment belongs to the compatible FUJI NXT machine family.

Check whether the machine configuration uses an H01 or H02 placement head.

This product is the 3.7G version.

Do not select only according to visual appearance because similar nozzles may exist.

Required model:

R36-037G-260

Required part number:

AA08520

Before ordering, compare the requested part with:

• Existing nozzle marking.
• Machine maintenance records.
• Previous purchase records.
• Production setup documents.
• Internal spare-parts list.

For continuous SMT production, keeping several frequently used nozzle models in spare inventory can reduce emergency purchasing delays.

Regular nozzle inspection helps maintain stable SMT production.

Clean the nozzle regularly.
Dust, production debris, and contamination may influence the vacuum path and pickup surface.

Inspect the vacuum passage.
A blocked or contaminated passage can reduce component holding performance.

Avoid physical damage.
Precision nozzle parts should be handled carefully during removal, cleaning, and installation.

Store models separately.
Clearly label each nozzle model to avoid mixing similar FUJI H01/H02 nozzle types.

Check before installation.
Inspect replacement nozzles before returning the machine to normal production.

Monitor repeated errors.
If one nozzle position repeatedly causes pickup errors, exchange the nozzle during diagnosis to determine whether the problem follows the nozzle.

A nozzle replacement should not automatically be considered the only solution. SMT production performance depends on the complete placement system.

The R36-037G-260 3.7G nozzle is used with compatible FUJI NXT SMT placement machines equipped with H01 or H02 placement heads.

The product described on this page is identified by model R36-037G-260 and part number AA08520. Providing both references is recommended when requesting a quotation.

Do not select only by the number 3.7. Confirm the complete model, including the G designation, part number, machine type, and placement head before replacement.

Provide the complete nozzle model, part number, machine model, head type, required quantity, and a clear photo of the existing nozzle if identification is uncertain.

Yes. Buyers requiring several nozzle models can prepare a complete list containing nozzle designation, model, part number, and quantity for combined quotation and purchasing.
