KOGANEI BDA10X5 Nozzle Side Lighting Cylinder for SAMSUNG CP40LV CP45

KOGANEI BDA10X5 Nozzle Side Lighting Cylinder for SAMSUNG CP40LV CP45

The KOGANEI BD is a compact multi-m10mm cyli, making it suitable

For SMT equipment applications, this cylinder can be supplied as a replacement component for compatible CP40LV, includ

Its compact block-style structure helps reduce installation space while delivering fast and repeatable linear movement. This makes it particularly useful for SMT ma

Because SMT machines may have different revisions and mechanical configurations, customers should verify the BDA before

Cause – Why the Cylinde

Pneumatic cylinders

Typical

When a cylinder us

This can influence machine stability and may eventually result in production interruptions.

Solution – Replace the Worn Pneumatic Cylinder

Installing the correct KOGANEI BDA10X5 cylinder provides a practical solution when the existing cylinder has become worn, damaged or unreliable.

The BDA series is designed around a compact square body with flexible mounting possibilities, making it suitable for machines where installation space is limited. KOGANEI lists BDA cylinders within its Multi Mount Cylinder family.

Using the correct cylinder specification can help restore:

• Stable pneumatic movement
• Consistent short-stroke positioning
• Reliable extension and retraction
• Smooth mechanical operation
• Reduced unexpected machine stoppage
• More predictable maintenance performance

For replacement applications, customers should compare the old cylinder directly with the replacement unit rather than selecting only by machine name.

Specifications

The BDA10X5 specification is independently listed as a 10 mm bore, 5 mm stroke, double-acting cylinder.

Key Advantages

Application

The KOGANEI BDA10X5 is suitable for compact pneumatic mechanisms in automated production equipment.

For SMT applications, it may be used in compatible machine assemblies requiring precise short-stroke linear motion.

Typical Application Areas

For CP40LV and CP45 equipment, machine revisions may differ. Confirm the installed cylinder before purchase.

How It Works

The BDA10X5 operates using compressed air.

As a double-acting pneumatic cylinder, air pressure is alternately supplied to the two sides of the internal piston. This creates controlled extension and retraction of the piston rod.

The operating process can be summarized as:

Compressed Air → Internal Piston Movement → Rod Extension or Retraction → Mechanical Positioning

In an SMT machine, this movement can be used to actuate a small mechanical assembly such as a lighting mechanism, positioning device or auxiliary actuator.

Because the stroke is only 5mm, the cylinder is particularly suitable for mechanisms requiring fast and short movement rather than long travel.

The compact BDA body also helps engineers integrate pneumatic motion where installation space is restricted.

Why a 5mm Stroke Matters

Small mechanisms inside SMT machines normally do not require large movements.

A short-stroke cylinder offers several practical advantages:

For this reason, 5mm-stroke cylinders are commonly selected for compact positioning and auxiliary automation mechanisms.

How To Choose the Correct Cylinder

Correct identification is especially important when purchasing SMT spare parts.

Do not select a replacement cylinder only according to the machine model.

Step 1 – Check the Cylinder Model

Look for the marking:

BDA10X5

The model should match the original installed unit.

Step 2 – Confirm Bore and Stroke

Required specification:

• Bore: 10 mm
• Stroke: 5 mm

Step 3 – Check Mounting Dimensions

Compare:

• Cylinder body size
• Mounting holes
• Rod position
• Installation orientation
• Pneumatic port position

Step 4 – Verify Machine Application

Confirm whether the cylinder is installed on:

• CP40LV
• CP45
• Related machine revision

Different machine versions may use different pneumatic components.

Step 5 – Send the Old Part Photo

For uncertain applications, send us:

Machine model + cylinder label + installation photo + required quantity

This is one of the safest ways to confirm compatibility before shipment.

Replacement Recommendations

When replacing the cylinder, technicians should inspect the surrounding pneumatic system at the same time.

Check:

A new cylinder cannot operate correctly if the connected pneumatic system has significant leakage or mechanical resistance.

Maintenance Suggestions

To help extend cylinder service life:

• Use clean and dry compressed air.
• Keep the cylinder body clean.
• Avoid excessive side load on the piston rod.
• Inspect air tubing periodically.
• Check for abnormal leakage.
• Avoid forcing the mechanism manually.
• Keep surrounding mechanical parts correctly aligned.
• Replace aging fittings when necessary.

Regular inspection can reduce unexpected machine downtime.

FAQ

1. What is the size of KOGANEI BDA10X5?

The BDA10X5 model uses a 10mm cylinder bore and 5mm stroke. It is a compact double-acting pneumatic cylinder designed for short linear movement.

2. Can BDA10X5 be used on CP40LV and CP45 machines?

It can be supplied for compatible CP40LV / CP45 applications when the original installed cylinder and mounting configuration match BDA10X5. Because machine revisions may differ, please verify the existing part marking before ordering.

3. What information should I provide before ordering?

Please provide the machine model, cylinder model, photos of the original part, installation position and required quantity. These details help us confirm the correct replacement quickly.

4. What are the symptoms of a damaged pneumatic cylinder?

Typical symptoms include air leakage, slow movement, incomplete extension, inconsistent retraction, unstable mechanism positioning and abnormal production interruptions.

5. Can you help confirm compatibility before shipment?

Yes. Send clear photos of the original cylinder and its identification marking together with your machine model. We can compare the specifications before quotation and shipment.

Contact Us

Need a replacement KOGANEI BDA10X5 pneumatic cylinder for your SMT equipment?

Send us your:

• Machine model
• Cylinder model
• Original part photo
• Installation position
• Required quantity

We can help check compatibility, availability and replacement options before quotation.

Send your inquiry now for price, stock status and delivery time.
