SAMSUNG HANWHA J6701028A BDAS6X15 Side Light Air Cylinder for SM482

SAMSUNG HANWHA J6701028A BDAS6X15 Side Light Air Cylinder is an important pneumatic component used in the side light mechanism of SM482 SMT placement machines. The cylinder provides controlled linear movement for the side lighting system, ensuring accurate positioning during PCB inspection and component placement processes.

In high-speed SMT production, stable lighting and precise mechanical movement are essential for reliable image recognition and placement accuracy. A properly functioning air cylinder helps maintain consistent operation of the vision system by controlling the movement of the side light assembly.

This replacement part is manufactured for SMT equipment maintenance, helping production lines restore machine performance, reduce downtime, and improve long-term equipment reliability.

Cause

During continuous SMT production, pneumatic components operate thousands of times every day. The side light air cylinder performs repeated extension and retraction movements, which may cause natural wear over time.

Common problems caused by aging or damaged air cylinders include:

A damaged side light cylinder may affect the stability of the SMT machine vision system. Since the placement machine depends on accurate image processing, unstable lighting movement can influence inspection reliability and machine operation.

Regular inspection and replacement of pneumatic spare parts are important for maintaining stable SMT production performance.

Solution

SAMSUNG HANWHA J6701028A BDAS6X15 Side Light Air Cylinder provides a reliable replacement solution for SM482 SMT machine maintenance.

By replacing worn pneumatic cylinders, manufacturers can restore accurate side light positioning and maintain stable machine operation.

Keeping original specification replacement parts available allows SMT factories to reduce unexpected downtime and improve maintenance efficiency.

Specifications

Compatible Equipment

Note:
Please confirm machine model and original part number before ordering to ensure compatibility.

Application

SAMSUNG HANWHA J6701028A BDAS6X15 Side Light Air Cylinder is mainly applied in SMT production lines equipped with SM482 placement machines.

Typical applications include:

The side light system supports the machine vision process by providing controlled illumination movement. Reliable pneumatic operation helps maintain consistent inspection conditions and improves overall placement accuracy.

How It Works

The BDAS6X15 air cylinder converts compressed air energy into linear mechanical movement.

Working process:

1. Compressed air enters the cylinder chamber.
2. Air pressure pushes the internal piston.
3. The piston rod moves the side light mechanism.
4. The side light reaches the required inspection position.
5. After signal control, the cylinder returns to the original position.

The pneumatic movement allows fast response and repeatable positioning, making it suitable for high-speed SMT equipment applications.

Maintenance Recommendations

Proper maintenance helps extend machine service life and improves SMT production stability.

How To Choose

When selecting a replacement side light air cylinder, consider the following factors:

1. Confirm Part Number

Verify that the original component number matches J6701028A.

2. Check Machine Model

Ensure compatibility with SAMSUNG HANWHA SM482 equipment.

3. Confirm Cylinder Specification

Check cylinder model BDAS6X15 and installation dimensions.

4. Select Reliable Replacement Parts

High-quality pneumatic components provide better stability and longer service life.

FAQ

Q1: What is SAMSUNG HANWHA J6701028A used for?
A1: J6701028A BDAS6X15 is a side light air cylinder used for controlling side light movement on SM482 SMT placement machines.

Q2: Which machine models use this air cylinder?
A2: This cylinder is mainly designed for SAMSUNG HANWHA SM482 SMT mounters.

Q3: What problems can a damaged air cylinder cause?
A3: A damaged cylinder may cause unstable side light movement, inspection issues, or machine operation errors.

Q4: Is J6701028A a complete replacement part?
A4: Yes, it is supplied as a replacement pneumatic cylinder component for compatible SMT machine maintenance.

Q5: How can I confirm compatibility before purchase?
A5: Please provide the machine model, original part number, or component photo for verification.

Contact Us

For SAMSUNG HANWHA J6701028A BDAS6X15 Side Light Air Cylinder availability, compatibility confirmation, and SMT spare parts support, please contact us.

We supply reliable SMT machine spare parts for SAMSUNG HANWHA, FUJI, JUKI, Yamaha, ASM/DEK and other major SMT equipment brands.
