Panasonic N210014666AC Nozzle Holder Spring for CM402 CM602 NPM Mounter

Panasonic N210014666AC Nozzle Holder Spring is a key mechanical component installed in the nozzle holder assembly of Panasonic SMT placement machines. It provides the necessary elastic force to maintain proper nozzle holder movement, positioning accuracy, and stable nozzle operation during component pick-up and placement.

In high-speed SMT production, nozzle stability directly affects component placement accuracy. A worn or weakened spring may cause abnormal nozzle movement, poor component pickup, or placement deviation. Replacing the original spring with a reliable N210014666AC replacement part helps restore machine performance and maintain smooth production operation.

This spare part is suitable for Panasonic CM402, CM602 and NPM series mounters, providing a cost-effective maintenance solution for SMT factories.

Cause

During continuous SMT operation, the nozzle holder spring performs repeated compression and release cycles during component pickup and placement. Long-term mechanical stress may gradually reduce spring elasticity and affect nozzle movement stability.

Common problems caused by aging nozzle holder springs include:

The nozzle holder assembly requires precise movement control because SMT placement machines operate with micron-level positioning accuracy. Even a small loss of spring force may influence nozzle performance and production quality.

Regular inspection and replacement of worn springs can help maintain stable machine operation and reduce unexpected downtime.

Solution

Panasonic N210014666AC Nozzle Holder Spring provides a reliable replacement solution for Panasonic SMT mounter maintenance.

By replacing damaged or weakened springs, production lines can restore proper nozzle holder operation and improve placement consistency.

Using a proper replacement spring helps extend nozzle assembly service life and supports stable PCB assembly quality.

Specifications

Compatible Equipment

Panasonic CM402, CM602 and NPM series are widely used SMT placement platforms requiring precise nozzle movement and stable component handling.

Note:
Please confirm the original part number and machine configuration before ordering.

Application

Panasonic N210014666AC Nozzle Holder Spring is mainly used in SMT production lines equipped with Panasonic high-speed placement machines.

Typical application fields include:

The nozzle holder spring plays an important role in maintaining stable nozzle movement. Reliable spring performance supports accurate component pickup, smooth placement operation, and improved production efficiency.

How It Works

The nozzle holder spring works as an elastic force component inside the nozzle holder mechanism.

Working process:

1. The placement head moves to the component supply position.
2. The nozzle moves downward to pick up the component.
3. The spring provides restoring force and maintains nozzle holder stability.
4. The component is transported to the PCB position.
5. The nozzle performs accurate placement and returns smoothly.

The spring ensures consistent mechanical movement and helps maintain the correct relationship between nozzle position and placement force.

Maintenance Recommendations

Regular maintenance of nozzle-related components helps reduce placement errors and improve SMT line productivity.

How To Choose

When selecting a replacement nozzle holder spring, consider the following factors:

1. Confirm Part Number

Verify that the original component number matches Panasonic N210014666AC.

2. Check Machine Model

Confirm compatibility with CM402, CM602 and NPM series placement machines.

3. Check Assembly Position

Ensure the spring is used for the correct nozzle holder mechanism.

4. Select Reliable Spare Parts

High-quality replacement springs provide stable force and longer operating life.

FAQ

Q1: What is Panasonic N210014666AC used for?
A1: Panasonic N210014666AC is a nozzle holder spring used to maintain stable nozzle holder movement on CM402, CM602 and NPM SMT mounters.

Q2: Which Panasonic machines are compatible with this spring?
A2: It is mainly designed for Panasonic CM402, CM602 and NPM placement machine series.

Q3: What happens when the nozzle holder spring wears out?
A3: A worn spring may cause unstable nozzle movement, poor pickup performance, or reduced placement accuracy.

Q4: Can this spring replace the original Panasonic part directly?
A4: Yes, N210014666AC is supplied as a replacement spare part for compatible Panasonic SMT equipment.

Q5: How can I confirm compatibility before purchase?
A5: Please provide your machine model, original part number, or photos of the component for verification.

Contact Us

For Panasonic N210014666AC Nozzle Holder Spring availability, compatibility confirmation, and SMT spare parts support, please contact us.

We provide reliable SMT machine spare parts solutions for Panasonic, FUJI, JUKI, Yamaha, SAMSUNG HANWHA, ASM/Siemens, DEK and other SMT equipment brands.
