YAMAHA KHJ-MC76U-00 SS56mm Feeder Waste Tape Cover for SMT Machine

YAMAHA KHJ-MC76U-00 SS56mm Feeder Waste Tape Cover for SMT Machine

The YAMAHA KHJ-MC76U-00 SS56mm Tail Cover Assembly is a replacement feeder component designed for 56mm SS series electric tape feeders used in automated SMT production equipment. The KHJ-MC76U-00 is identified in feeder parts references as a TAIL COVER ASSY for the 56mm feeder configuration.

Mounted at the rear section of the feeder, this component provides a protective and guiding structure around the outgoing carrier tape area. A properly fitted tail cover helps maintain organized waste tape movement and protects the feeder tail mechanism from unwanted contact during loading, unloading, operation, and maintenance.

It is particularly suitable for maintenance departments, SMT factories, equipment service companies, and feeder repair workshops requiring replacement parts for worn, cracked, missing, or damaged SS56mm feeder components.

Cause – Why the Feeder Tail Cover Needs Replacement

Although the tail cover does not directly perform component pickup, its condition can influence the mechanical protection and tape handling around the rear of the feeder.

Common reasons for replacing the KHJ-MC76U-00 include:

Frequent feeder changeovers, transportation between production lines, improper storage, accidental impact, and long operating periods can gradually damage feeder exterior components.

Replacing a damaged cover before it affects surrounding parts is a simple preventive maintenance measure that can help reduce unnecessary feeder downtime.

Solution – Replace the Damaged SS56mm Tail Cover

When the existing feeder rear cover becomes damaged or cannot be securely installed, replacing it with the correct KHJ-MC76U-00 56mm tail cover assembly restores the required physical structure at the feeder tail.

The replacement solution provides several practical benefits:

• 1. Correct 56mm Feeder Configuration
  Designed specifically for the SS56mm feeder size rather than smaller 8mm, 12mm, 24mm, 32mm, or 44mm feeder configurations.
• 2. Stable Mechanical Installation
  The correct part number helps ensure alignment with the corresponding feeder mounting structure.
• 3. Better Waste Tape Management
  Provides an organized area around the outgoing carrier tape and feeder tail mechanism.
• 4. Protection During Daily Operation
  Helps protect the feeder rear mechanism against accidental contact during installation, removal, transport, and storage.
• 5. Convenient Maintenance Replacement
  A practical replacement choice when repairing feeders rather than replacing the complete feeder assembly.

Specifications

The KHJ-MC76U-00 is consistently identified in feeder parts references as the 56mm TAIL COVER ASSY, distinguishing it from KHJ-MC66U-00 for 44mm and KHJ-MC56U-00 for 32mm feeder configurations.

Application

The KHJ-MC76U-00 is primarily used for maintenance and repair of 56mm SS electric tape feeders.

Typical applications include:

Public feeder-parts listings associate KHJ-MC76U-00 with SS56mm electric feeder accessories used in YS12 and YS24 applications.

For equipment with different feeder configurations, compatibility should always be checked by the feeder model, feeder width, and existing part number before ordering.

How It Works

During SMT operation, carrier tape passes through the feeder while components are indexed toward the pickup position. After the component section has passed through the feeding mechanism, the remaining carrier material is directed toward the rear section of the feeder.

The tail cover provides a structured protective area around this section.

The operating process can be summarized as:

Carrier Tape Loading → Tape Indexing → Component Feeding → Used Tape Exit → Rear Tape Management

The KHJ-MC76U-00 does not control feeder pitch or component positioning electronically. Instead, it serves as a mechanical feeder tail component, helping maintain the correct physical arrangement and protection of the feeder rear area.

This distinction is important when troubleshooting.

If a feeder experiences pitch errors, motor errors, communication faults, or inaccurate component positioning, the cause may involve another feeder component. If the rear cover is cracked, loose, missing, or physically obstructing the tape path, inspection of the KHJ-MC76U-00 should be included in the maintenance process.

How To Choose

Selecting feeder spare parts only by appearance can result in incorrect ordering because different feeder widths often use similar-looking components.

Before purchasing, verify the following information:

Important Feeder Width Difference

Several related tail cover assemblies exist for different SS feeder widths:

The part-number-to-width relationship is documented in feeder spare-parts references.

Do not select KHJ-MC66U-00 or KHJ-MC56U-00 as a substitute simply because their external appearance is similar. The feeder width should match the required specification.

For purchasing departments managing several feeder sizes, providing a clear photo of the existing feeder together with the feeder width and part number can significantly reduce selection errors.

Why Choose This Replacement Part

• Correct SS56mm Specification
  The KHJ-MC76U-00 is specifically identified for the 56mm feeder configuration.
• Maintenance-Friendly Replacement
  Replace the damaged component individually without unnecessary replacement of a complete feeder.
• Suitable for Regular Spare-Part Inventory
  Useful for SMT factories operating multiple feeders and maintaining spare units for preventive maintenance.
• Fast Model Confirmation
  Part number and feeder width provide clear identification before shipment.
• Suitable for International SMT Maintenance
  Appropriate for electronics manufacturers, EMS factories, feeder repair companies, and SMT equipment maintenance teams.

FAQ

Q1: What is YAMAHA KHJ-MC76U-00?

KHJ-MC76U-00 is a tail cover assembly used with a 56mm SS electric feeder. It is installed around the feeder rear section and provides mechanical protection and organization around the outgoing carrier tape area.

Q2: Is KHJ-MC76U-00 suitable for a 56mm feeder?

Yes. KHJ-MC76U-00 is identified as the tail cover assembly for the SS56mm feeder configuration. Confirm the existing feeder model and part number before purchase to avoid confusing it with similar covers for other widths.

Q3: Can KHJ-MC76U-00 be used for YS12 and YS24 feeder applications?

Parts references list KHJ-MC76U-00 as an SS56mm feeder accessory associated with YS12 and YS24 applications. Compatibility should still be confirmed according to the actual feeder model and feeder configuration before ordering.

Q4: When should the feeder tail cover be replaced?

Replacement is recommended when the cover is cracked, deformed, loose, missing, difficult to install, or physically interfering with the waste carrier tape area. Early replacement helps prevent additional mechanical problems around the feeder tail.

Q5: What information should I provide before ordering?

Please provide KHJ-MC76U-00, feeder width 56mm, feeder model, required quantity, and preferably a clear photo of the existing component. This allows faster compatibility confirmation and reduces the possibility of ordering the wrong feeder part.

Contact Us

Need KHJ-MC76U-00 SS56mm feeder tail covers for maintenance, feeder repair, or production-line spare stock?

Send us your part number, feeder model, required quantity, and delivery country. We can help confirm the correct feeder specification and prepare a quotation for your purchasing requirement.

Send your inquiry today for price, stock availability, lead time, and shipping options.
