FUJI 2AGTHA004600 2SGTHA000500 2AGTHA009100 Precision NXT H24 Nozzle Shaft

The FUJI 2AGTHA004600, 2SGTHA000500, and 2AGTHA009100 NXT H24 Head Nozzle Shaft is a precision mechanical component used within the nozzle mechanism of an H24 placement head. It is designed for FUJI NXT pick-and-place equipment and supports accurate, smooth, and repeatable nozzle-axis movement during component pickup and placement operations.

This shaft may also be described as an H24 syringe shaft, nozzle holder shaft, placement-head shaft, or nozzle driving shaft. It is commonly required when the installed component becomes worn, scratched, bent, contaminated, or mechanically damaged.

The product is suitable for preventive maintenance, placement-head rebuilding, emergency repair, and factory spare-parts inventory. Original and compatible supply options may be available according to stock, delivery requirements, and customer specifications. Because different part numbers can represent different revisions or assembly configurations, buyers should provide the machine model, H24 head label, old part number, photographs, and dimensions for confirmation.

The nozzle shaft performs frequent vertical movement during normal SMT placement operations. In high-volume production, the component may complete millions of movement cycles while working inside the placement head.

Mechanical wear, contamination, nozzle collision, incorrect maintenance, or improper installation can gradually reduce movement accuracy. A damaged shaft may cause intermittent faults before a complete machine failure occurs.

A nozzle shaft problem may produce one or more of the following symptoms:

• Nozzle movement is slower than normal.
• The nozzle does not return smoothly.
• Pickup errors occur intermittently.
• Placement accuracy becomes unstable.
• The head produces abnormal mechanical noise.
• The nozzle height appears inconsistent.
• The shaft shows visible scratches or wear.
• The nozzle mechanism sticks during manual checking.
• Placement rejection rates increase unexpectedly.
• A machine alarm appears after head movement.
• The installed shaft is visibly bent.
• Repeated nozzle-related errors occur on the same head position.

These symptoms can also be caused by nozzles, springs, holders, seals, sensors, vacuum components, feeders, component presentation, or machine calibration. The complete head mechanism should therefore be inspected before replacing the shaft.

Replacing a worn or damaged H24 nozzle shaft can help restore controlled movement inside the placement-head mechanism. The correct replacement must match the required head version, part number, physical dimensions, mounting structure, surface condition, and installation position.

A structured verification and replacement process reduces incorrect-part risks.

The shaft should not be selected by appearance alone. Precision SMT head components can look similar while having different lengths, diameters, end structures, grooves, shoulders, mounting features, or production revisions.

The shaft is manufactured as a precision placement-head component. Controlled dimensions and a properly finished functional surface help support smooth movement within the H24 nozzle mechanism.

The product is intended for maintenance and repair of FUJI NXT equipment fitted with an H24 placement head. It can be used during preventive servicing, emergency repair, and head rebuilding.

The listing includes part references 2AGTHA004600, 2SGTHA000500, and 2AGTHA009100, helping buyers locate the product using different purchasing records or maintenance references.

Different supply options may be available. The offered product condition and supply type will be stated clearly in the quotation.

Orders can be checked according to the part number, machine model, head label, photographs, dimensions, and customer sample before shipment.

The shaft is individually protected to reduce the risk of scratching, contamination, impact, or deformation during international transportation.

The following table is designed for product identification. It does not guarantee that every listed number is directly interchangeable.

The three part numbers may refer to related products, production revisions, subassemblies, or different H24 head configurations. Similar product descriptions do not automatically confirm identical dimensions or direct replacement.

Before replacing one reference with another, customers should verify:

The H24 head nozzle shaft is suitable for factories, maintenance departments, service companies, and distributors working with FUJI NXT SMT placement equipment.

EMS factories often operate multiple SMT lines for different customer projects. Maintaining suitable H24 head components can help reduce repair delays and support consistent machine availability.

High-volume production of household electronics, smart devices, displays, and related circuit boards requires stable pickup and placement performance. Worn head components should be replaced during scheduled maintenance.

Automotive electronics production normally requires documented maintenance, controlled replacement procedures, and stable equipment performance. Part-number verification is especially important before installation.

The shaft can support NXT equipment used for manufacturing controllers, sensors, power modules, inverters, industrial communication products, and automation devices.

Manufacturers of routers, communication modules, networking products, and signal-processing boards can include nozzle shafts in their placement-machine spare-parts inventory.

LED board production can involve long operating hours and repeated placement cycles. Regular head inspection helps identify contamination, wear, and abnormal nozzle movement.

Facilities assembling medical electronic products can use verified replacement components within their approved maintenance and quality-control procedures.

Professional service providers may use the component during H24 head inspection, rebuilding, repair, and functional testing.

Distributors can supply the nozzle shaft to factories operating NXT placement machines. Different references and revisions should be separately labeled and stored.

The H24 placement head uses multiple nozzle positions to pick electronic components from feeders and place them onto programmed PCB locations. The nozzle shaft forms part of the mechanical structure that supports controlled vertical nozzle movement.

A simplified placement sequence is described below:

1. The placement head moves to the component pickup position.
2. The selected nozzle mechanism moves downward.
3. The nozzle reaches the programmed pickup height.
4. Vacuum is applied through the nozzle system.
5. The electronic component is picked from the feeder.
6. The component is lifted and transported by the head.
7. The machine checks component position and orientation.
8. The head moves to the programmed PCB coordinate.
9. The nozzle descends to the placement height.
10. The component is released onto the solder-paste position.
11. The nozzle returns to its starting position.
12. The machine continues to the next programmed cycle.

The shaft must maintain smooth and stable movement throughout this process. Bending, contamination, scratches, incorrect dimensions, or installation misalignment may increase friction and affect nozzle return.

Replacing only the shaft may not solve the problem if the guide, spring, seal, holder, nozzle, or another related component is also damaged.

Verify that the equipment belongs to the FUJI NXT series. Provide the complete model rather than writing only “NXT machine.”

Check whether the machine is equipped with an H24 placement head. Send a clear photograph of the head label.

Check maintenance records, labels, purchasing history, and the removed component for one of the following references:

• 2AGTHA004600
• 2SGTHA000500
• 2AGTHA009100

Photographs should clearly show:

• Complete shaft profile
• Both end structures
• Main body surface
• Grooves and shoulders
• Holes or threaded areas
• Locating or mounting details
• Original label or packaging
• Installation position inside the head

Use suitable precision measuring tools and avoid scratching the original shaft during measurement.

For emergency maintenance, consider ordering the immediate replacement quantity together with additional spare stock. Large factories can set minimum inventory levels according to machine quantity, operating hours, and historical failure records.

Complete inquiry information helps reduce quotation time and incorrect ordering risks.

The nozzle shaft should be inspected as a precision mechanical component before shipment.

Compatible components should normally be evaluated through an initial sample order before large-volume purchasing.

Installation should be completed by qualified SMT maintenance personnel familiar with FUJI NXT placement heads.

• Stop the machine according to factory safety procedures.
• Remove the head using the approved maintenance process.
• Work in a clean and well-lit area.
• Prepare suitable precision tools.
• Record the original assembly sequence.
• Compare the new shaft with the removed component.
• Inspect the guide, holder, spring, seal, and nozzle.
• Confirm that the replacement has no visible damage.

• Do not force the shaft into the guide.
• Do not hit the shaft with metal tools.
• Do not touch precision surfaces with dirty hands.
• Keep dust, fibers, oil, and metal particles away.
• Install retaining components in the correct sequence.
• Use only approved lubricant where lubrication is required.
• Confirm free movement before completing assembly.
• Replace damaged related components when necessary.

• Check shaft movement manually where permitted.
• Confirm that the nozzle returns freely.
• Reinstall the head according to the machine procedure.
• Complete the required calibration.
• Run a controlled pickup test.
• Run a low-risk placement program.
• Check nozzle return and component pickup.
• Inspect trial boards.
• Record the maintenance date and replacement part number.

Do not grind, polish, bend, straighten, or modify the shaft without an approved technical process. Modification can change critical dimensions and surface characteristics.

Precision shafts can be damaged by impact, contamination, vibration, or contact with other metal products. Suitable export packaging is therefore essential.

1. Confirm the part number and ordered quantity.
2. Inspect the shaft surface.
3. Place the shaft in an individual protective sleeve or bag.
4. Protect both ends and functional surfaces.
5. Add cushioning material.
6. Place the item in a suitable inner box.
7. Secure the inner box inside the export carton.
8. Apply product and quantity labels.
9. Seal the outer carton.
10. Prepare the required shipping documents.

We supply placement-head components, nozzles, feeders, feeder parts, motors, sensors, valves, control boards, cables, filters, belts, and other SMT machine parts.

Products can be checked according to machine models, part numbers, labels, samples, photographs, and dimensions.

Original and compatible supply options may be quoted according to customer requirements, stock availability, quality expectations, and delivery schedules.

We support emergency maintenance orders, regular factory purchasing, distributor inventory, and consolidated spare-parts shipments.

Protective packaging and flexible transportation options are available for customers in Europe, North America, Southeast Asia, and other global markets.

No. Compatibility depends on the installed H24 placement-head version, machine configuration, and required part number. Please provide the complete machine model, head identification label, old shaft photographs, dimensions, and required quantity before ordering.

Direct interchangeability should not be assumed. These references may represent different revisions, configurations, or assembly positions. The old part number, physical structure, dimensions, head label, and installation position should be verified before replacement.

Original and compatible supply options may be available depending on stock and customer requirements. The quotation will clearly state the offered product condition and supply type so that customers can select the appropriate option.

Please send the required part number, complete FUJI NXT machine model, H24 head label, clear product photographs, critical dimensions, required quantity, destination country, preferred supply type, and expected delivery date.

Yes. The product can be consolidated with nozzles, feeders, feeder parts, motors, sensors, valves, cables, filters, control boards, conveyor parts, and other SMT machine components to simplify purchasing and transportation.

FUJI and related machine names are trademarks of their respective owners. They are used only to describe product compatibility and intended application.

The listing does not imply authorization, sponsorship, or affiliation unless specifically stated in the quotation. Original and compatible supply options will be identified separately. Customers should verify all part numbers and application information before ordering.

Please include the part number, complete NXT machine model, H24 head label, required quantity, delivery country, and clear photographs in your inquiry.
