FUJI 2AGTBC001300 FH1578B4F Remote IO Board for NXT III M6

The FUJI 2AGTBC001300 FH1578B4F Remote IO Board is an electronic control component designed for FUJI NXT III M6 SMT pick and place equipment. It functions as part of the machine's distributed input and output control system, supporting signal communication between the main control architecture and related sensors, actuators, switches, pneumatic devices, and functional modules.

In modern SMT production, stable I/O communication is essential because multiple machine functions must operate in precise sequence. An unstable or damaged I/O board may result in communication alarms, missing device signals, abnormal machine status, or unexpected production interruptions.

For purchasing and maintenance, both identification references should be checked carefully: FUJI part number 2AGTBC001300 and board model FH1578B4F. Matching the exact board information before installation can help reduce incorrect replacement and purchasing errors.

This product is suitable for SMT factories, electronics manufacturers, maintenance departments, equipment service companies, and spare parts distributors operating FUJI NXT III production lines.

Cause

Why May a Remote IO Board Require Replacement?

Electronic control boards operate continuously in SMT production environments. Long operating hours, electrical stress, contamination, connector wear, or component aging may eventually affect communication stability.

Common situations that can lead technicians to inspect the Remote IO Board include:

A machine alarm does not always mean the board itself has failed. Technicians should also inspect cables, connectors, sensors, actuators, and power conditions before replacing the board.

Solution

When the NXT III M6 shows a remote I/O related fault, a structured inspection process helps identify the problem more efficiently.

Recommended Troubleshooting Process

Step 1: Check the Alarm Information

Record the machine alarm code, affected module, and operating condition when the fault occurs.

Step 2: Inspect Connectors and Cables

Check for:

• Loose connections
• Damaged cables
• Bent contacts
• Contamination
• Poor terminal contact
• Incorrect installation

Step 3: Check Peripheral Components

Sensors, valves, switches, cylinders, and other controlled devices should be tested before determining that the board is defective.

Step 4: Confirm the Existing Board

Verify the identification information:

• FUJI Part Number: 2AGTBC001300
• Board Model: FH1578B4F
• Machine Series: NXT III
• Application: NXT III M6

Step 5: Replace the Confirmed Faulty Board

When troubleshooting confirms that the board is faulty, use a replacement matching the required part number and board specification.

Step 6: Perform Machine Testing

After installation, perform the appropriate initialization, I/O inspection, alarm confirmation, and production test according to the machine maintenance procedure.

Specifications

Important Compatibility Note

Board revision, connector configuration, machine configuration, and other identification markings should be compared with the original installed board before ordering. Similar-looking control boards should not automatically be considered interchangeable.

Identification Information

Providing both 2AGTBC001300 and FH1578B4F when requesting a quotation can make product identification faster and more accurate.

Related Model Comparison

Although both boards may be associated with the NXT III M6 control system, they have different part numbers and board models. They should not be treated as direct replacements for each other without machine-specific confirmation.

Application

The FUJI 2AGTBC001300 FH1578B4F Remote IO Board is suitable for a variety of SMT production and maintenance environments.

SMT Production Lines

Used in FUJI NXT III M6 placement equipment where reliable control communication is required for continuous production.

Electronics Manufacturing

Suitable for factories producing:

• Consumer electronics
• Automotive electronics
• Industrial control products
• Communication equipment
• Medical electronic assemblies
• Power electronics
• PCB assemblies

Maintenance Departments

The board can be maintained as a critical spare for troubleshooting and emergency replacement.

Equipment Service Companies

Service engineers supporting FUJI NXT equipment can use exact part number identification to improve repair efficiency.

Spare Parts Distribution

The combination of FUJI part number and FH board model provides convenient identification for international SMT spare parts procurement.

Typical Users

How It Works

The Remote IO Board works as part of the communication pathway between the machine control system and distributed input and output devices.

A simplified operating process is:

Sensor or Device → Remote IO Board → Machine Controller → Control Logic → Remote IO Board → Output Device

Input Communication

Sensors and switches provide status information suchs as:

• Device position
• Presence detection
• Mechanical status
• Cylinder position
• Module readiness
• Safety condition

The Remote IO Board transfers these input signals into the machine control system.

Control Processing

The central controller evaluates the incoming signal according to the programmed operating sequence.

Output Communication

After processing the input status, the machine sends commands to the related output devices.

Depending on the machine configuration, these may include:

• Pneumatic valves
• Relays
• Actuators
• Indicators
• Control modules
• Other machine devices

Stable communication is therefore important for coordinated machine operation.

Why Reliable I/O Communication Matters

SMT placement equipment operates through precise timing and continuous device feedback.

A typical control sequence may include:

1. A mechanism reaches its required position.
2. A sensor confirms the position.
3. The I/O system sends the status signal.
4. The controller verifies the operating condition.
5. The next command is generated.
6. An output device performs the required action.
7. Production continues.

If one required signal becomes unstable or unavailable, the machine may interrupt its operating sequence.

For this reason, a properly functioning Remote IO Board is an important part of maintaining stable equipment performance.

How To Choose

Selecting an SMT control board requires careful identification. Do not choose only according to appearance.

1. Check the Part Number

Confirm:

2AGTBC001300

The exact FUJI part number should be the first selection reference.

2. Check the Board Model

Confirm:

FH1578B4F

The FH model provides an additional identification reference.

3. Confirm the Machine

Verify that the existing application corresponds to:

FUJI NXT III M6

4. Compare the Original Board

Check the original component for:

5. Provide a Product Photo

If you are unsure about compatibility, send a clear photo showing:

• Complete PCB
• Part number label
• FH model marking
• Connector area
• Existing board markings

6. Confirm Required Quantity

For factories operating several NXT III machines, keeping an additional critical control board in stock may reduce waiting time when an unexpected failure occurs.

Maintenance and Storage

Electronic control boards should be handled carefully.

ESD Protection

Use appropriate electrostatic discharge protection during handling and installation.

Clean Environment

Keep the board away from:

• Moisture
• Conductive dust
• Oil contamination
• Chemical vapors
• Excessive heat

Connector Protection

Avoid impact or pressure on board connectors during transportation and storage.

Protective Packaging

Electronic boards should be individually packed using suitable protective materials to reduce the risk of static electricity and physical damage.

Purchasing Checklist

Providing complete purchasing information helps reduce identification errors and shortens quotation time.

3. FAQ and Contact Us

FAQ

Q1: What machine is the FUJI 2AGTBC001300 FH1578B4F Remote IO Board used for?

The board is designed for FUJI NXT III equipment and is listed for NXT III M6 applications. Always compare the original part number, board model, and machine configuration before ordering.

Q2: What is the function of the FH1578B4F Remote IO Board?

It supports remote input and output signal communication between the machine control system and related sensors, actuators, switches, and functional devices used within the SMT placement equipment.

Q3: How can I confirm that I need 2AGTBC001300?

Check the original board label and confirm FUJI part number 2AGTBC001300, model FH1578B4F, machine model, connector layout, and other visible markings before requesting a replacement.

Q4: Can 2AGTBC000500 FH1622A0F directly replace this board?

Do not assume direct interchangeability. The two products use different part numbers and board models. Compatibility should be verified according to the exact NXT III M6 configuration and original installed board.

Q5: What information is required for a fast quotation?

Please provide part number 2AGTBC001300, model FH1578B4F, required quantity, machine model, destination country, and a clear photo of the original board for accurate identification.

Contact Us

Need the FUJI 2AGTBC001300 FH1578B4F Remote IO Board for NXT III M6?

Send us your part number, board model, required quantity, machine model, and product photo for fast compatibility checking and quotation.

We support inquiries from SMT factories, electronics manufacturers, maintenance departments, equipment service companies, and spare parts distributors.

Send your inquiry today for price, stock availability, condition options, and delivery information.
