Panasonic CM402 Y Axis Servo Driver

KXFP6GB0A00 / Mitsubishi MR-J2S-100B-EE085

Professional Motion Control Solutions for SMT Pick and Place Machines

The Panasonic KXFP6GB0A00 Y Axis Servo Driver, powered by Mitsubishi MR-J2S-100B-EE085, is a high-performance AC servo amplifier designed for Panasonic CM series SMT pick and place machines, especially the CM402 platform.

This servo driver controls the Y-axis motion system, which performs the primary linear movement of the placement head. It converts digital motion commands from the machine controller into precise electrical drive signals for the servo motor, ensuring high-speed positioning, stable acceleration, and high-accuracy component placement.

Role of Y Axis in Panasonic CM Architecture

In Panasonic CM machines, the Y-axis defines machine travel range, placement throughput, head synchronization, and system cycle efficiency.

Axis Functions

X-axis: Horizontal positioning
Y-axis: Main forward and backward movement
Z-axis: Vertical pick & place
Theta-axis: Rotation and alignment

Y-Axis Instability Consequences

Placement deviation
Vision alignment error
Servo alarms
Emergency stops
Production downtime

Key Product Specifications

Product Name	AC Servo Driver / Servo Amplifier
Panasonic Part No.	KXFP6GB0A00
Mitsubishi Model	MR-J2S-100B-EE085
Machine Model	Panasonic CM402
Axis	Y Axis
Rated Power	1000W
Control Type	Digital AC Servo

Mitsubishi MR-J2S Servo Technology

The MR-J2S series belongs to Mitsubishi's MELSERVO J2-Super platform, widely used in SMT machines, CNC systems, robotics, semiconductor equipment, and precision automation.

Key Features

High-speed current loop control
High-resolution encoder feedback
Real-time torque regulation
Intelligent protection functions

This ensures smooth acceleration, zero overshoot, and micron-level positioning accuracy even in high-load industrial environments.

Servo Control Principle

The servo system operates using three nested closed loops that enable high response speed, stable motion under heavy load, low vibration, and long-term reliability.

Control Loops

Current Loop: Controls instantaneous motor torque
Speed Loop: Regulates motor speed under dynamic load
Position Loop: Ensures exact final positioning

Panasonic CM Series Compatibility

CM212 / CM202

Axis	Driver Model	Panasonic Part No.	Motor Model	Motor Part No.
Y	MR-J2S-70B-EE085	KXFP6F97A00	HC-MFS73-S24/S23	N510005280AA / KXF0DWXSA00
X	MR-J2S-40B-EE085	KXFP6GE1A00	HC-MFS43-S24/S25	N510005279AA / KXF0CWNAA00

CM602

Axis	Driver Model	Panasonic Part No.	Motor Model	Motor Part No.
Y	MR-J2S-100B-EE085	KXFP6GB0A00	HC-RFS103-S1	KXF0CWLAA00
X	MR-J2S-40B-EE085	KXFP6GE1A00	HC-MFS43-S24/S25	N510005279AA / KXF0CWNAA00

CM602 (High Power Version)

Axis	Driver Model	Panasonic Part No.
Y	MR-J2S-350B-S041U703	N510002594AA
X	MR-J2S-60B-S041U638	N510002593AA

Typical Failure Symptoms

Symptom	Root Cause
Axis not moving	Power module failure
Servo alarm	Protection circuit triggered
Random stop	Overcurrent or overheating
Position drift	Encoder signal instability
Communication error	Interface circuit fault

Common Failure Causes in SMT Machines

Heat accumulation inside cabinets
Dust contamination on PCB
Unstable power supply
Capacitor aging after 5-7 years
Poor grounding or EMI interference

Servo drivers usually fail electronically and suddenly, not mechanically.

Safety & Usage Notes

Always power off before wiring
Wait at least 15 minutes after power-off
Never touch terminals when powered
Ensure proper grounding (PE)
Do not expose to oil mist or moisture
Ensure cabinet ventilation

Incorrect operation may result in electric shock, fire hazard, or permanent equipment damage.

Preventive Maintenance Strategy

Production Mode	Recommendation
Normal factory	Replace after failure
High-speed lines	Keep spare in stock
24/7 operation	Preventive replacement after 5-7 years
Old machines	Backup driver mandatory

Downtime cost is always much higher than servo driver cost.

Replacement Benefits

Restore axis accuracy
Eliminate random alarms
Improve production stability
Extend machine service life
Reduce maintenance risk

Available Condition Options

New - Original brand new
Used - Original used, fully tested
Refurbished - Repaired and performance verified

All units undergo power-on test, alarm self-check, communication verification, and load simulation (if required).

Packaging & Delivery

Item	Details
Packaging	Anti-static + foam
Shipping	DHL / FedEx / UPS / Air / Sea
Protection	Shock-resistant
Delivery Area	Worldwide

SEO Keywords

Panasonic CM402 Servo Driver, KXFP6GB0A00, MR-J2S-100B-EE085, Panasonic CM Series Servo, SMT Servo Amplifier, Pick and Place Servo Driver, Mitsubishi Servo Drive, Panasonic SMT Spare Parts

Contact us today for pricing and technical confirmation of Panasonic CM402 Y Axis Servo Driver - KXFP6GB0A00 / MR-J2S-100B-EE085.

Please provide your machine model and error code for fast verification. Professional technical support available for Panasonic and Mitsubishi motion systems.
